FMS Reflex V2 Gyro Flight Controller Gyro

FMS REFLEX V2 GYRO FLIGHT CONTROLLER

We are proud to introduce the new and improved FMS Reflex V2!

A user-upgradable flight controller

Reflex V2 can be reprogrammed easily with different model files via a simple software-allowing pilots to use the same flight control unit as they progress to different aircraft. Flying is simple when you have your very own “co-pilot”- the Reflex V2!

Reflex Functions

• 3 flight modes are available: Stabilized, Optimized or off. This is controlled with a 2 or 3 position switch on the transmitter. When assigned to a 2 position switch, the Reflex system switches between stabilized and optimized modes.
• Stabilized Mode – Designed for beginners, Reflex will rapidly level the aircraft from any attitude when this mode is activated. Stabilized mode combines accelerometer and gyro data to determine how to level the aircraft when the control sticks are released- giving pilots absolute peace of mind.
• OFF – Turns off all gyro functionality, the aircraft is flown completely manually when the gyro is off.
• Optimized Mode – Utilizing advanced solid-state gyros, the Reflex system maintains aircraft attitude by counteracting inflight upsets- from gusts to crosswinds.

FMS compatible with the following airplanes (other models to come in the future…)

• 1400mm Pitts V2
• 1400mm 182
• 1700mm F4U V3
• 980mm P-40
• 1100mm MXS V2
• 1200mm CJ-6
• 1800mm Ranger
• 1220mm Super EZ
• 1700mm F7F
• 1100mm PC-21
• 1400mm J3 V4
• 1700mm PA-18
• 80mm Rafale
• 70mm F-18 V2
• 80mm BAE Hawk
• 80mm Futura V3
• 80mm F-4
• 70mm A-10 V2
• 70mm Avanti V3
• 2000mm Beaver V2
• 1220mm Ranger
• 1500mm P-51
• 1400mm F4U
• 1100mm Zero
• 1400mm Kingfish
• 800mm F-4U
• 800mm T-28
• 750mm Edge540
• 1400mm P51
• 1400mm P40
• 1100mm F3A
